Equipment Tags

Print these tags and attach them to your equipment. Field workers scan the marker image with the AR app to automatically load the associated guide.

Back to App

How Tag Scanning Works

  1. Print the marker image for each piece of equipment and attach it visibly to the unit.
  2. When a field worker points their phone camera at the marker in AR mode, the system recognizes it and automatically loads the matching guide.
  3. Each guide has one marker image. The tag IDs listed below are alternate lookup codes (e.g., for manual entry or QR codes).
  4. Currently all guides share the same default marker. In production, each guide would have a unique marker image.
Scan marker for Industrial Pump Controller
Scan this marker
Industrial Pump Controller
Maintenance and repair guide for the Model X-200 industrial pump controller unit.
Tag IDs
markerpump-controllerdefault
Available Tasks (6)
  • Visual Inspection inspection
  • Full Disassembly repair
  • Replace Filter Cartridge maintenance
  • Motor Service maintenance
  • Calibrate Pressure Gauge operation
  • Control Board Replacement repair
